Important OMG-OCSMP-MBA400 Exam Questions

Answer: B

Explanation:

The SysML diagram type that is a modification of the UML Composite Structure diagram is the Internal Block Diagram (IBD). An IBD shows the internal structure of a block in terms of its parts, ports, connectors, and flows. It is similar to a UML Composite Structure diagram, but it adds some features specific to SysML, such as flow ports, flow specifications, item flows, nested connectors, etc. Reference: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://sysml.org/tutorials/sysml-diagram-tutorial/

Answer: A

Explanation:

A trade study is a method for making a decision between competing alternatives based on a set of criteria, such as cost, performance, reliability, etc. A trade study allows a user to objectively determine the best means of implementing a particular function by evaluating and comparing the pros and cons of each alternative.A trade study can also help identify trade-offs and risks associated with each alternative

Answer: D

Explanation:

The SysML diagram type that is a modification of the UML Class diagram is the Block Definition Diagram (BDD). A BDD shows the definition of blocks in terms of their features, such as properties, operations, ports, etc. It is similar to a UML Class diagram, but it adds some features specific to SysML, such as value types, units, flow properties, etc. A block is an extension of the UML Class metaclass that can be used to model any system component with structure and behavior. Reference: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://sysml.org/tutorials/sysml-diagram-tutorial/

Answer: A

Explanation:

The OMG specifications that UPDM uses at L1 are UML and SysML. L1 is the level of abstraction that defines the core concepts of UPDM without any implementation details. It is based on a Domain Metamodel that captures the common elements of DoDAF and MODAF. The Domain Metamodel is mapped to UML and SysML concepts using a Platform Independent Model (PIM). UML and SysML provide the basic metaclasses and diagrams that UPDM uses to represent architectures. Reference: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://www.omg.org/updm/

Answer: C

Explanation:

The diagram fragment that correctly expresses the requirement that the model must only be built using the constructs defined in the Quality profile is Option C. This option shows an apply relationship between the model and the profile with the {strict} keyword applied. This means that only elements with stereotypes from the Quality profile can be created as instances of the extended metaclasses. Reference: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://www.ibm.com/docs/SSB2MU_8.2.0/com.ibm.rhp.sysml.doc/topics/rhp_c_dm_sysml_profile_features.html
