Important Nutanix NCM-MCI Exam Questions

Answer: A

Explanation:

To configure traffic segmentation on an unconfigured node, you need to run the following commands on the node:

manage_ovs --bond_name br0-up --bond_mode active-backup --interfaces eth0,eth1 update_uplinks manage_ovs --bridge_name br0-up --interfaces eth2,eth3 --bond_name bond1 --bond_mode balance-slb update_uplinks

These commands will create a bond named br0-up with eth0 and eth1 as active and passive interfaces, and assign it to the default bridge. Then, they will create another bond named bond1 with eth2 and eth3 as active interfaces, and assign it to the same bridge. This will enable traffic segmentation for the node, with eth2 and eth3 dedicated to the segmented traffic and configured to use both links in a load-balancing mode.

I have replaced the x in the file Desktop\Files\Network\unconfigured.txt with the appropriate character or string for you. You can find the updated file in Desktop\Files\Network\configured.txt.

manage_ovs --bond_name br0-up --bond_mode active-backup --interfaces eth0,eth1 update_uplinks

manage_ovs --bridge_name br1-up --interfaces eth2,eth3 --bond_name bond1 --bond_mode balance_slb update_uplinks

https://portal.nutanix.com/page/documents/solutions/details?targetId=BP-2071-AHV-Networking:ovs-command-line-configuration.html

Answer: A

Explanation:

Here is the step-by-step solution to create and export the capacity planning scenario. This task is performed within Prism Central.

1. Navigate to the Planning Dashboard

From the Prism Central main menu (hamburger icon), navigate to Operations > Planning.

2. Create and Define the Scenario

Click the + Create Scenario button.

In the dialog box:

Scenario Name: IaaS

Scenario Type: Select New Workload

Click Create. This will open the scenario editor.

3. Configure Cluster and Runway Settings

In the 'IaaS' scenario editor, find the Runway setting (top left) and set it to 12 Months.

Find the Cluster configuration tile and click Edit.

Set Number of Host Failures to Tolerate to 2.

Click Save.

4. Define the Workload Profile

In the Workloads section, click the + Add Workload button.

Select Create a new workload profile.

Fill in the VM specifications:

Workload Name: Customer-VM (or similar)

vCPU per VM: 4

Memory per VM: 16 GB

Storage per VM: 200 GB

Click Add.

5. Set the Workload Growth Plan (Waves)

You will be returned to the main scenario editor. In the timeline section ('Workload Plan'), add the VMs:

Wave One (Today):

Click + Add under the 'Today' column.

Select the Customer-VM profile.

Enter 100 VMs.

Click Add.

Wave Two (3 Months):

Click the + icon on the timeline itself.

Set the date to 3 Months from today.

Click + Add under this new '3 Months' column.

Select the Customer-VM profile.

Enter 50 VMs.

Click Add.

Wave Three (6 Months):

Click the + icon on the timeline.

Set the date to 6 Months from today.

Click + Add under this new '6 Months' column.

Select the Customer-VM profile.

Enter 20 VMs.

Click Add.

6. Select the Hardware

In the Hardware configuration tile, click Change Hardware.

In the 'Select Hardware' pane:

Model: Search for and select DX365-10-G11-NVMe.

Note: This model is full-flash by definition, satisfying the requirement.

Click Done. The planner will recalculate the required nodes.

7. Save and Export the Scenario

Click the Save icon (floppy disk) in the top-right corner to save the IaaS scenario.

Click the Export icon (arrow pointing down) in the top-right corner.

Select PDF from the dropdown menu.

A 'Save As' dialog will appear.

Navigate to the Desktop.

Set the file name to IaaS-requirement.pdf.

Click Save.
